Autel Maxiscope MP408 4-Channel Oscilloscope for Vehicles – Portable Diagnostics

Others
Condition: New

$592.27

Autel MaxiScope MP408 is a 4-channel oscilloscope for modern vehicles, usable with PC or MaxiSys tablets. USB-powered, portable, it reads, displays, records, and plays back high-resolution waveforms, supports LIN, CAN, FlexRay, and includes probes and accessories.

Stock Status: In Stock
Delivery Status: 1-3 days
Excluding Tax: $0
Compare
Add to wishlist
Category:
Description

Autel Maxiscope MP408 4-Channel Oscilloscope for Vehicles – Portable Diagnostics

  • Experience powerful diagnostics with the Autel MaxiScope MP408, a 4-channel oscilloscope designed for modern vehicles.
  • Works with PC or MaxiSys tablets, turning your setup into a portable high-precision diagnostic lab.
  • USB-powered—no batteries required—streamlined, highly portable operation.
  • Reads, displays, records, and plays back high-resolution waveforms with color-coded controls for quick analysis.
  • Supports LIN, CAN, and FlexRay data buses for versatile vehicle testing.
  • One-click auto setup for voltage scale and time base; manual parameter adjustment available.
  • Includes comprehensive test leads, probes, and accessories for ready-to-use performance.
  • Channels:
    		•  4
  • Bandwidth:
    		•  20 MHz
  • Sampling rate (single shot):
    		•  up to 80 MS/s with 1 or 2 channels; up to 20 MS/s with 3 or 4 channels
  • Vertical resolution:
    		•  12 bits
  • Input ranges (full scale):
    		•  ±50 mV to ±100 V in 11 ranges
  • Input impedance:
    		•  1 MΩ in parallel with 22 pF
  • Input type:
    		•  Single-ended, BNC connector
  • Input coupling:
    		•  Software-selectable AC/DC
  • Overload protection:
    		•  ±200 V on a single input
  • Power:
    		•  USB-powered from connected PC; no external battery required
  • Storage and waveform buffers:
    		•  up to 1000 waveforms; 105k samples shared among active channels
  • Operating temperature:
    		•  32°F to 122°F (59°F to 104°F for quoted accuracy)
